极化polarization: ±45°
频段frequency range: 820-960/1710-2170mhz
水平波瓣horizontal-3db beam-width: 65°
增益gain: 17/18 dbi
电子倾角electrical downtilt: 0-10°/0-10°
|
型号type |
ta08091721651718dvt |
||
|
电气性能指标electrical specifications |
|||
|
频带frequency range (mhz) |
820-960 |
1710-2170 |
|
|
增益gain (dbi) |
17*2 |
17.5*2 |
|
|
极化polarization |
±45° |
±45° |
|
|
水平波束宽度horizontal-3db beam-width (°) |
65 |
65 |
|
|
垂直波束宽度vertical-3db beam-width (°) |
9 |
7 |
|
|
电下倾角electrical down-tilt (°) |
0-10 |
0-10 |
|
|
第一旁瓣抑制first upper side-lobe suppression (db) |
≥16 |
≥16 |
|
|
第二旁瓣抑制second upper side-lobe suppression (db) |
/ |
≥15 |
|
|
交叉极化比 cross polar ratio (db) |
0° |
≥15 |
≥15 |
|
|
±60° |
≥10 |
≥10 |
|
前后比front-to-back ratio (db) |
≥25 |
≥25 |
|
|
驻波比v.s.w.r |
≤1.45 |
||
|
端口隔离isolation between two ports (db) |
≥30 |
||
|
三阶无源交调pim3 (dbm/dbc) |
≤-110/153 |
||
|
输入阻抗impedance (ω) |
50 |
||
|
雷电保护lightning protection |
直流接地direct ground |
||
|
最大功率maximum input power (w) |
500 |
300 |
|
|
机械性能指标 mechanical specifications |
|
|
天线罩材料 radome material |
upvc |
|
接头形式 connector type |
7/16din((f)×4 |
|
天线尺寸 dimension (l/w/h)(mm) |
2526×278×139 |
|
包装尺寸 packing size(l/w/h)(mm) |
2746×320×203 |
